Self-adhesive Rubber Insulation Mat for HVAC Ducts

FOAM-G

Self-adhesive Rubber Insulation Mat FOAM-G

The FOAM-G insulation mat is a self-adhesive mat made of synthetic rubber, designed for insulating flat and cylindrical surfaces, including rectangular and round ventilation ducts. This product effectively reduces condensation and provides both thermal and acoustic insulation. Thanks to its closed-cell structure, the mat is characterized by low water vapor permeability.

Key Features

Self-adhesive application
Made from synthetic rubber
Effective anti-condensation insulation
Thermal and acoustic insulation properties
Ideal for insulating ventilation ducts
Closed-cell structure
Low water vapor permeability
Available in various thicknesses

Dimensions

Mat thickness G [mm]	Roll width D [mm]	Quantity m²/roll
6*	1000	30
9*	1000	20
13*	1000	14
19*	1000	10
25*	1000	8
32	1000	6
50	1000	4

*Thicknesses available in stock

Technical Data

Parameter	Standard	Value
Thermal conductivity λ W/(m*K)	EN 12667	0.032 (-20°C) 0.034 (0°C) 0.036 (+20°C) 0.038 (+40°C) 0.040 (+60°C)
Water vapor permeability μ	EN 12086	μ ≥ 7000
Temperature range	EN 14706	-40°C / +85°C
Fire resistance	EN 13501-1	B-s3, d0
