The FLKA-C-D clamp is a special version of a clamping ring, designed for ventilation systems requiring high tightness. Its steel construction includes a clamp with an adjustable screw and a hinge, facilitating installation and removal. A key element is the use of a special FLKA-EPDM-OMEGA gasket, whose unique, wider, and flared shape at the clamp edge guarantees increased connection tightness. According to the measurement methodology of PN-EN 12237:2005, the use of the FLKA-C-D clamp achieves a result in tightness class D.
| Product Code | Diameter ØD [mm] |
|---|---|
| FLKA-C-D-100 | 100 |
| FLKA-C-D-125 | 125 |
| FLKA-C-D-150 | 150 |
| FLKA-C-D-160 | 160 |
| FLKA-C-D-180 | 180 |
| FLKA-C-D-200 | 200 |
| FLKA-C-D-225 | 225 |
| FLKA-C-D-250 | 250 |
| FLKA-C-D-300 | 300 |
| FLKA-C-D-315 | 315 |
| FLKA-C-D-350 | 350 |
| FLKA-C-D-400 | 400 |
| FLKA-C-D-450 | 450 |
| FLKA-C-D-500 | 500 |
| FLKA-C-D-550 | 550 |
| FLKA-C-D-600 | 600 |
