Symmetric Square Duct Reducer from Plastic Materials

PVC-QPR6F

Symmetric Square Duct Reducer from Plastic Materials

The symmetric reducer is designed for the efficient connection of two rectangular ventilation ducts with different cross-sectional dimensions. It is manufactured from high-quality plastic sheets, with thickness adapted to the specific dimensions of the fitting, ensuring durability and a tight connection. Dimensions provided in the catalog always refer to the external dimensions of the fitting.

Key Features

Connects rectangular ventilation ducts of varying cross-sections.
Constructed from plastic sheets of appropriate thickness.
Available in versions with a socket (PVC-QPR6F) or with a flange (PVC-QPR6T).
Wide range of materials: PVC, PPs (flame-retardant), PVCW (white), PP, PPELS (electrically conductive), PE, PVDF.
Dimensions are given as external dimensions of the fitting.

Technical Data

Designation	Material
PVC-QPR6F	Polyvinyl chloride PVC
PPs-QPR6F	Flame-retardant polypropylene PPs
PVCW-QPR6F	White polyvinyl chloride PVCW
PP-QPR6F	Polypropylene PP
PPELS-QPR6F	Electrically conductive flame-retardant polypropylene PP-EL-s
PE-QPR6F	Polyethylene PE
PVDF-QPR6F	PVDF material
