Pre-insulated Bends IZOL system BSLI

BSLI-90
Photo of product BSLI-90

Pre-insulated Bends IZOL®system BSLI ALNOR

BSLI pre-insulated bends are part of the ALNOR IZOL®system double-wall ductwork range. Each bend consists of an inner duct bend fitted with an EPDM rubber gasket and an outer protective duct jacket without gaskets. Designed to provide efficient thermal and acoustic insulation in HVAC ventilation systems.

Key Features

  • Double-wall construction: Inner duct bend with EPDM gasket and outer protective jacket.
  • High airtightness: Built-in EPDM rubber gasket ensures excellent air tightness.
  • Insulation thickness options: Available in 10 mm, 16 mm, and 25 mm insulation layers.
  • Multiple bend angles: Available in 90° (BSLI-90), 60° (BSLI-60), 45° (BSLI-45), 30° (BSLI-30), and 15° (BSLI-15) angles.
  • Wide diameter range: Inner diameters ranging from 80 mm to 500 mm.

Technical Data

Parameter Value
Product type BSLI pre-insulated duct bend
System IZOL®system ALNOR
Inner seal EPDM rubber gasket
Outer jacket Without gasket
Insulation thickness 10 mm, 16 mm, 25 mm
Available angles 15°, 30°, 45°, 60°, 90°
Inner diameter range (Ød) 80 - 500 mm
